Bronze Gate Valve - Z600B DN80

Promet Valves - Z600B

AS 2129 E Flange, non-rising stem cast bronze valve with inside screw, bolted cover and integral seats.

Body: Cast Bronze LG2

Wedge: Cast Bronze LG2

Fasteners: Stainless Steel

Cover: Cast Bronze LG2

Packing: PTFE

Stuffing Box: Cast Bronze LG2

Spindle: DR: Brass

Handwheel: Bronze

Pressure: 1400 KPA (200 PSI)

Dimensions:

Distance between flanges: 172mm

Flange Diameter: 187mm

Flange ID: 80mm

Bolt PCD: 146mm

Bolt Holes: 4

Bolt Hole Diameter Ø: 18mm

Height from centre of flange to top of spindle: 309mm

Height Overall: 410mm

Mass Kg: 18

Pre-owned surplus spare in excellent serviceable condition.

Please contact Myles Marine Engineering for further information and shipping estimates.
